1.Dog food production line pet feed making machine Main Features:
1).Our processing line adopt international advanced technology, the pellets size are very even.
2).we can adjust the cutter speed and the dies to get the different diameter and the length product
3).The Electric heating device system can control the temperature accurately
4).High temperature and high pressure can kill the salmonellosis andbacterial infections.
5).This dog food production line can produce high-protein dog food.
6).This pet food line only need three workers
Flow chart :grinding→mixing→extruding→drying→flavoring→cooling→packing
Our engineer could design the layout drawing according to your dimension of the factory for the dog food machines
2.Machine parameters
Model | Installed Power (kw) | Power Consumption (kw) | Capacity (kg/h) | Dimension (m) |
65 processing line | 74 | 52 | 120-180 | 17*1.2*2.2 |
70 processing line | 95 | 70 | 200-300 | 20*1.5*2.2 |
75 processing line | 110 | 82 | 250-400 | 26*1.5*2.2 |
85 processing line | 139 | 104 | 400-800 | 28*3.5*4.3 |
90 processing line | 132 | 75 | 800-1200 | 28*3.5*4.3 |
95 processing line | 165 | 90 | 1500-2000 | 35*3.5*4.3 |
120 processing line | 469 | 380 | 2000-2500 | 45*20*22 |
135 processing line | 712 | 570 | 3000-3500 | 50*20*25 |
3.Raw material:Rice flour, corn flour, wheat flour, low temperature soya flakes meal, rice bran , wheat bran, fish powder, bone powder etc.
4.Equipment list in the dog food production line:
Name | Mixer |
Usage | To mix the raw materials evenly, fast speed, no leakage. |
Type | including Single axle and double shaft mixer |
Motor | 3kw, 4kw, 7.5kw etc. |
Capacity | 20kg/time, 50kg/time, 100kg/time, 200kg/time, 500kg/time etc. |
Material | stainless steel, carbon steel |
Name | Twin screw extruder(wet type/dry type) |
Usage | To extrude the raw materials and make them to the required shape and size of the dog food pellets by mould |
model | FLD65, 70, 75, 90, 95, 120, 135 |
Motor | 22kw, 30kw, 55kw, 75kw, 90kw, 110kw etc. |
Capacity | 100kg/h to 10 ton/h |
Material | Screw materials 38CrMoAl |
Name | Dryer (oven) |
Usage | the expanded food go through the "s" passage, to be dried to increase the self life. |
Type | electrical, steam, gas fired, diesel fired heating type |
Motor | KX-3-5, KX-5-5, KX-5-8, KX-5-10, KX-7-10 etc. |
Capacity | 100kg/h to 10 ton/h |
Material | stainless steel, carbon steel |
Name | Flavoring machine |
Usage | To mix the oil and flavors on the surface of the pet food |
Type | single and double flavoring drum |
Motor | 0.75kw |
Capacity | 100kg/h to 10 ton/h |
Material | stainless steel |
Name | Packaging machine |
Usage | To pack the dog feed with required weight |
Flowing Process | Manual Bag placing→Automatic filling→Automatic weighing→ Automatic bag conveyor→Automatic bag sewing or heat sealing |
Weight range | 1-5kg/bag, 5-25kg/bag, 25-50kg/bag |
Material | stainless steel, carbon steel |
Type | Automatic |
